POWERCOM TC-650-3000HT Traffic Control 650-3000 watt PSW High Temp inc Batt Lead Australia 2
Powercom UPS Australia

Traffic Control 2000 watt PSW High Temp inc Batt Lead

$3,636.00 AUD inc. GST

Line Interactive Pure Sine Wave (PSW)  Rack/Tower Mountable with Terminal Input/Output.
For External 48VDC Battery Bank Only (Battery Lead Included). Consult Powercom UPS Aus for  Sizing and Cost.

UPS
Model
TC-2000HT
Capacity VA
2000 VA
Capacity (Watts)
2000 W
INPUT
Voltage
120VAC ±25%, 220 / 230 / 240VAC ±25%
Frequency Range
120 Vac 60Hz 220 / 230 / 240Vac 50/60Hz
OUTPUT
Waveform
Pure Sine Wave
Voltage
120VAC ±25%, 220 / 230 / 240VAC ±25%
Frequency
50 / 60 Hz ± 0.5 Hz
Transfer Time
Normal Mode(Max): 12 ms Generator | Mode(Max): 25 ms
AC Input & Output Connectors
Terminal block, anderson PP45 quick connector, IEC socket
PROTECTION
Full Protection
Overload (110% for 3 min), Circuit Breaker
BATTERY
Type
Lead-acid battery
UPS Model
TC-2000
String Voltage
48 VDC
Charging Temperature Compensation
-2.5/-3.0/-4.0/-5.0 mV/Deg C/Cell (-3.0mV default)
Max Charge Current
10A, ( 2-12A Adjustable )
INDICATORS
LED Display
Output status, alarm, fault LED
LCD Display
4 line multi-function LCD
MANAGEMENT
Communication Port
RS232 , USB B Type, SNMP card (Option)
Dry Contacts
6 Programable Output contacts & 1 Programable Input contact
ENVIRONMENT
Operating Humidity
0 ~ 95 % RH (Non-condensing)
Audible Noise
Less than 60 dB
Storage Temperature
-50 ~ 75°C
Operating Temperature
-37 ~ 74°C
PHYSICAL
Dimension (W×D×H)(mm)
432 x 254 x 133
Weight (kgs)
21
Shipping Dimensions (mm)
540 x 388 x 277
Shipping Weight (kgs)
23
